| Technical data |
|
Accessory group: |
Plug connectors and cables |
|
|
Accessory family: |
Connection cables with male connector and male connector |
|
|
Connection type head A: |
Male connector, M12, 4-pin, angled, D-coded
|
|
|
Connection type head B: |
Male connector, M12, 4-pin, straight, D-coded |
|
|
Locking plug connector: |
Schraubbarer |
|
|
Locking nut material: |
Zinc die-cast, nickel-plated |
|
|
Cable diameter: |
Ø 6.4 mm |
|
|
Сечение провода: |
2 x 2 x 0.14 mm² |
|
|
Shielding: |
Shielded |
|
|
Bending radius: |
26 mm |
|
|
Status LED: |
- |
|
|
Reference voltage: |
60 V |
|
|
Current loading: |
4 A |
|
|
Signal type: |
EtherNet/IP |
|
|
Ambient operating temperature: |
-20 °C ... +80 °C |
|
|
Enclosure rating: |
(M12) IP 65 / IP 67 |
|
|
Cable: |
10 m, 4-wire, CAT5, CAT5e |
|
|
Jacket material: |
PUR, halogen-free |
|
|
Jacket color: |
Wasserblau |
|
